16mm Momentary Push Button Switch R13-507 Reset 250V 3A

AC 250V/3A AC125V/6A

Size: approx. 24 x 19 x 19 mm ,Screw head diameter: approx. 16 mm

16mm Momentary Push Button Reset Switch Specifications

The R13-507 momentary push button switch is a 16mm reset switch designed for reliable electronic control applications. This push button features a compact design with precise electrical ratings suitable for both AC 250V/3A and AC 125V/6A circuits, making it versatile for various electrical projects and control panels.

Technical Specifications

This momentary push button switch measures approximately 24 x 19 x 19 mm in overall dimensions, with a screw head diameter of approximately 16mm for standard panel mounting. The 16mm mounting size is a common industry standard, ensuring compatibility with existing panel cutouts and mounting hardware.

The electrical rating of AC 250V at 3A or AC 125V at 6A provides flexibility for different voltage requirements. The momentary action means the switch returns to its original position when released, making it ideal for reset functions, test circuits, and momentary control applications.

Applications and Use Cases

This R13-507 push button switch is suitable for control panels, electronic test equipment, industrial machinery, DIY electronics projects, and educational laboratory setups. The momentary contact configuration makes it particularly useful as a reset button, test switch, or any application requiring temporary circuit activation.

The 16mm diameter mounting hole requirement is standard across many control panel applications, allowing for easy integration into existing systems or new builds. The compact 24mm overall size ensures the switch fits in tight spaces while maintaining easy operation.

Installation and Mounting

Installation requires a 16mm diameter mounting hole in your panel or enclosure. The screw-type mounting provides secure attachment and professional appearance. The compact depth of 19mm allows installation in shallow panels where space behind the mounting surface is limited.

Quality and Reliability

Built to handle the specified current ratings of 3A at 250V AC or 6A at 125V AC, this momentary push button switch provides reliable operation for frequent use applications. The momentary action ensures consistent performance in reset and control functions where temporary contact is required.
