Arduino UNO R3 / MEGA Sensor Expansion Shield V5.0
This V5.0 sensor expansion shield fits both the Arduino Uno R3 and the Arduino Mega 2560, converting every available pin to a 3-pin VCC/GND/signal socket for direct sensor module connection. The shield detects which board it is seated on by alignment — it covers all 14 digital and 6 analogue pins on the Uno, or all 54 digital and 16 analogue pins on the Mega. An I2C header, a Bluetooth header, and an SD card socket are included for common peripheral connections.
- Fits Uno R3 and Mega 2560 — one shield for both boards
- 3-pin sensor sockets on all pins — VCC, GND, signal per socket
- I2C header and Bluetooth serial header
- Micro SD card slot — for data logging
- All sockets labelled — pin function printed next to each socket
Best for
Sensor kit experiments on Uno and Mega, data logging with SD card, multi-sensor robotics builds, and any project needing clean plug-in sensor connections on either board.
Why Kunkune
Shipped from UK stock. 60-day returns, no minimum order. Fast Royal Mail delivery.
Buying in bulk? For classroom orders, contact us for trade pricing.
